Filemagic

Filemagic is a file uploader with a beautiful and simple interface, built with React on frontend and using Refile gem on backend to upload to S3.

Showcase demo here

Install

Dependencies:

Gemfile

Add:

• gem 'sprockets', '~> 3.4.0'
• gem 'sprockets-es6', '~> 0.8.0'
• gem "refile-mini_magick", "~> 0.2.0"

Remove:

• gem 'turbolinks'

JavaScript

Filemagic is jQuery dependent, it uses many jQuery plugins:

• jQuery fileupload
• jQuery UI
• jQuery UI Widget
• jQuery Iframe Transport Plugin

So ensure your project imports jQuery.

application.js

• remove turbolinks
• require filemagic

application.css

• require/import filemagic

application.html.erb

• remove turbolinks from stylesheet and javascript tags

Configuration

Create a filemagic.rb file on config/initializers. If using S3 to cache/store files needs to have refile cache/store configurated, if S3 cache/store is not set on initializer file Refile will use host FileSystem to store images.

require "refile/s3"

aws = {
  access_key_id: Rails.application.secrets.aws_access_key_id,
  secret_access_key: Rails.application.secrets.aws_secret_access_key,
  region: Rails.application.secrets.aws_region,
  bucket: Rails.application.secrets.aws_bucket,
}

Refile.cache = Refile::S3.new(prefix: "cache", **aws)
Refile.store = Refile::S3.new(prefix: "store", **aws)

Refile.cdn_host = Rails.application.secrets.cdn_host if Rails.env.production?

Add mount route to routes.rb

mount Filemagic::Engine => "/filemagic"

S3 Bucket CORS config

Add a CORS xml configuration file to your S3 bucket. Cross-origin resource sharing (CORS) defines a way for client web applications that are loaded in one domain to interact with resources in a different domain.

<CORSConfiguration>
  <CORSRule>
    <AllowedOrigin>http://localhost:3000</AllowedOrigin>
    <AllowedMethod>GET</AllowedMethod>
    <AllowedMethod>POST</AllowedMethod>
    <AllowedMethod>PUT</AllowedMethod>
    <AllowedHeader>*</AllowedHeader>
  </CORSRule>
</CORSConfiguration>

Usage

Add a field to desired model (eg: cover_image)

rails g migration add_cover_image_id_to_posts cover_image_id:string

Add field as attachment on model:

class Post < ActiveRecord::Base
  attachment :cover_image
end

Add input on form:

<%= f.filemagic_field :cover_image %>

Whitelist attribute on strong parameters controller:

def post_params
  params.require(:post).permit(:title, :cover_image)
end

To call images on any view, use attachment_url helper:

image_tag attachment_url(post, :cover_image, :fill, 100, 100)

Input options

Filemagic input have some options to customize:

1. Preview size

Preview size can be customized with a preview_size option:

<%= f.filemagic_field :cover_image, preview_size: {width: '100px', height: '100px'} %>

2. Actions

Action Buttons can be activated per field with an array passed through actions:

<%= f.filemagic_field :cover_image, actions: ['remove', 'reposition'] %>

2.1 Remove

Add a remove button, allowing user to set a new or remove a file from model

2.2 Reposition

Allow user to reposition image inside a visible window. Like a crop, but it's not a crop. (Crop feature will be able soon). Important: reposition feature stores values on model as coordinates, so it depends on having 2 string attributes on model:

• <name_of_field>offset_x
• <name_of_field>offset_y

Create a migration:

rails g migration add_cover_image_offset_to_posts cover_image_offset_x cover_image_offset_y

And edit migration file to have default to +0

  t.string :cover_image_offset_x, default: '+0'
  t.string :cover_image_offset_y, default: '+0'

License

This project rocks and uses MIT-LICENSE
